WR578
5G Industrial PoE-PSE Router
WR578 is a cellular industrial router supporting 5G/4G/3G mobile connectivity, 4 PoE-PSE GE ports compliant with the 802.3af and 802.3at standards, Wi-Fi 6, serial ports and abundant I/O ports. Plus WAN failover, WR578 is able to provide reliable Gigabit-class data links for digital networking.
PRODUCT GALLERY
3D MODEL
PRODUCT SHOWCASE
• 4*PoE-PSE GE Port + Wi-Fi 6 + 5G
• 3GPP Rel-16 Complied, support sub-6GHz NSA and SA mode
• IEEE 802.11 a/b/g/n/ac/ax
• 802.3af and 802.3at compliant, PoE-Out up to 30W per port
• 1*RS232 + 1*RS485 + 7*DI + 2*DO + 1*AI+1*RELAY
• WAN failover between ETH WAN and Cellular WAN
• VPN: PPTP, L2TP, IPSec, GRE, OpenVPN, WireGuard
• Modbus, MQTT
• Management: Web GUI, SSH, TR069, SNMP, SMS, RMS
COMPATIBLE ACCESSORIES
Sim Eject Pin
Ethernet Cable
Wi-Fi SMA Antenna
GNSS SMA Antenna
Cellular SMA Magnetic Antenna
Cellular SMA Antenna
Female DB9 Connector with Wires
L Type Mounting Bracket
FAQ
Can WR578 power connected PoE devices?
Yes. WR578 has four Gigabit Ethernet PoE-PSE ports compliant with IEEE 802.3af and 802.3at, delivering up to 30 W per port. Size the power supply for the router and the combined load of the connected PoE devices.
What connections does WR578 offer besides PoE Ethernet?
WR578 combines sub-6 GHz 5G SA and NSA, Wi-Fi 6 AX1800, one RS232 port and one RS485 port. It also provides digital inputs and outputs, an analog input and a relay.
How should WR578 be powered?
WR578 uses a four-pin Molex power connector and supports a 48–58 V DC input. Select a power supply that covers both the router and its connected PoE loads, and check the ordered unit's rating before installation.
Can WR578 switch to cellular if its Ethernet WAN fails?
Yes. WR578 supports failover between Ethernet WAN and cellular WAN. Configure the primary and backup connections and the failure-detection policy for your deployment. Existing sessions may need to reconnect when the WAN changes.
Can WR578 support VPN access and industrial data communication?
Yes. WR578 supports WireGuard, OpenVPN and IPsec for VPN access, as well as Modbus TCP client/server and MQTT broker, publisher and gateway functions. Configure VPN routing and the required device data mapping for your application.
