WR143

LTE Cat 4 Industrial Router

WR143 is expertly designed for the M2M and IoT industries. With its compact form factor, two Ethernet ports, serial port and I/O ports, WR143 ensures your devices remain connected and responsive.

Inquire now

LTE Cat 4

Dual Sim

Serial + I/O

WAN Failover

PRODUCT GALLERY

3D MODEL

PRODUCT SHOWCASE

Hardware

Ethernet

2*10/100Mbps Port

Cellular

LTE Cat 4

Wi-Fi

2.4GHz

Serial Port

1*RS232 or 1*RS485

Software

Network

Multi-WAN: ETH WAN, Cellular WAN
WAN Failover, Load Balancing

Protocols

PPPoE, TCP, UDP, DHCP, NAT, DNS, NTP, SMTP, Telnet,ICMP, HTTP, HTTPS, TLS, ARP, VLAN, SSH2, DDNS

Cellular

LTE Cat 4
SMS, Dual-APN, Band Lock, PIN Management, IP Passthrough
Sim auto-switch

Wi-Fi

Standard: IEEE 802.11b/g/n
Frequency: 2.4GHz
Security: WPA-PSK, WPA2-PSK, WEP
Encryption: AES, TKIP
Wi-Fi Users: Up to 16 Users
Whitelist, Blacklist

VPN

PPTP, L2TP, IPSec, GRE, OpenVPN, WireGuard

MQTT

MQTT Broker, MQTT Publisher
MQTT Gateway
Data to Server

Modbus

Supported Mode: Server, Client
Supported Types: TCP
Supported Data Formats:8-bit INT / UINT, 16-bit INT / UINT, 32-bit float / INT / UINT, HEX, ASCII

Routing

Static Route, Policy Route, BGP, OSPF, RIP, NHRP, VRRP

Security

Firewall, DMZ, Anti-DDOS, Website Filtering, Access Control, 802.1x

Device Management

Web GUI, SSH, TR069, SNMP, SMS, RMS

• Compact design
• 4G LTE Cat 4 Access
• 1*PoE-PD FE + 1*FE
• 1*RS232 or RS485 + 2*I/O
• WAN failover between ETH WAN and Cellular WAN
• VPN: PPTP, L2TP, IPSec, GRE, OpenVPN, WireGuard
• Modbus, MQTT
• Management: Web GUI, SSH, TR069, SNMP, SMS, RMS
